Floor Deck roll forming Machine

YX60-211.5-845 Floor Deck roll forming Machine,steel decking machine,Deck panel roll forming machine PRODUCT FEATURE AND USAGE The designing of metal deck roll forming machine is aided and optimized by computer. The metal deck produced by this machine has high strength with big wavelength. It adheres well to concrete. Used on high buildings, it not only saves steel mold plate, but also reduced the weight of storey. With the same bearing capacity, it economizes steel and cuts down investment accordingly.TECHNOLOGY SPECIFICATION The metal deck formed by this machine has strong strength with high pitches. It's best to be used as the floor of high buildings, and the cost of such floor is low.Main Date Material: Galvanized steel sheet Thickness of raw material: 0.8-1.2mm Nodal distance: Adjustable according to requirement (>=250mm) Main motor power: 15 kW Hydraulic motor power: 3kW Working speed: 10-12m/min Total weight: About 11.6MT Voltage: 380V 3 phase 60Hz or as per the customers' requirements Control system: PLC control The designing of metal deck forming machine is aided and optimized by computer. Material of cutter: Cr12 roll stand:25 Raw Material Specification Galvanized steel sheet Size of material: 1250 x (0.6-1.2) mm x L mm
